Imperial Locks G5012 6in, 5L Horizontal Mortice lock.

5 Lever horizontal mortice lock for use on internal wooden hinged doors providing a high level of security.

CE Marked door lock Fire rated to BS EN 1634-1:2000 & Performance rated to BS EN 12209.

Latchbolt operated by knob from either side.
Deadbolt operated by key from either side.
Supplied with 2 keys, striker plate and fixing screws.

Finishes stainless steel (SS) or satin brass (SB).

A datasheet and catalogue page can be downloaded from the link below.

G5012 catalogue page
G5012 datasheet
  • Finish
Finish:Select
Quantity
Remove Add
  • Operation - Latchbolt operated by knob from either side Deadbolt operated by key from either side
  • Case - Pierced to accept 38mm centre horizontally opposed bolt through fixing furniture
  • Striker Plate - Type B with dust box DB1
  • Latchbolt - Brass, reversible. Projection 12mm
  • Deadbolt - Brass, with two hardened steel rollers. Throw 16mm
  • Follower - Brass, to suit 8mm square spindle Two-way action
  • Differs - 200 standard differs numbered 001-200
  • Rebate Units - To Suit, G3057-13mm G3058-19mm G3059-25mm
  • Dimensions:
  • A - Lock Case - 151mm
  • B - Backset - 57mm
  • C - Centres - 70mm
