Union HD26 Heavy Duty Tubular Latch

Product code: Select Options

Select Options
x
Dundee Depot2
Elgin Depot28
Inverness Depot213
From £7.30 (£6.08 +VAT)
Delivery Truck Logo

£6.95

Or Free Collection From Store

Union HD26 Heavy duty tubular latch.

Suitable for doors hinged on the left or right.
Latch bolt withdrawn by the lever handle from either side.

Supplied with both polished brass and satin stainless steel square forends and strike plates.

Both 2.5" and 3" cases pierced to accept bolt through furniture.
Bolt through fixings allows a more secure, longstanding fixing of door furniture overtime when compared to handles fixed with woodscrews.

Suitable for sprung and light unsprung lever furniture.

Full datasheet can be downloaded from link below.

Union HD26 datasheet
  • Size
Size:Select

Quantity:

  • Heavy duty tubular latch for doors hinged on the left or right
  • Supplied with both polished brass and satin stainless steel forends and strike plates.
  • Latch bolt withdrawn by the lever handle from either side
  • Pierced to accept bolt through furniture
  • Bolt through fixings allows a more secure, longstanding fixing of door furniture overtime when compared to handles fixed with woodscrews
  • Suitable for sprung and light unsprung lever furniture.
  • Profiled beveled latch bolt for smooth and positive engagement during operation
  • Double sprung allowing universal handing
  • Supplied with an adjustable formed strike complete with a splinter guard for a professional finish
  • Profiled beveled latch bolt for smooth and positive engagement during operation
  • Two piece forend supplied with a dual finish in stainless steel and polished brass finish
  • Double sprung allowing universal handing
  • Available with square forend and strike
  • Supplied with an adjustable formed strike complete with a splinter guard for a professional finish
  • Reference: HD26

Case Size: 2.5' (70mm) and 3' (82mm)
Backset: 45mm and 57mm
Case: Steel, galvanised
Inner Forend: Steel, radius
Outer Forend: Dual finish supplied with both Stainless steel and Polished Brass finish
Striking Plate: Adjustable, dual finish supplied with both Stainless steel and Polished Brass finish
Splinter Guard: Black plastic
Latch Bolt: Zinc, brass appearance
Follower: 8mm cast steel
  • Tested to BS EN 12209:2003
  • 2 M 4 1 0 F - B 0 2 0
  • EN 1634-1 assessed for use on 30 and 60 minutes timber fire doors
  • CE Marked: EC Certificate 0086-CPR-633283
  • DoP: 101MLB which can be found at www.uniononline.co.uk/DoP
  • In addition to EN12209 requirements HD Tubular Latches have been cycle tested
    for over 1 million cycles through the follower
    and slam tested on the latch
  • 10 year guarantee
